Answer only * Vandal resistant .125" thick panel * Double gang box mount or VE-5x10 ; Applications: Automated tellers, courtesy and emergency phones, info Kiosks

The K-1500 Series provides simple vandal resistant, communication in a flush mount, stainless steel, panel telephone. The K- 1500-7 and K-1500-6 work ideally with Viking’s DLE-200B line simulator or on a dedicated ringdown circuit. If dialing is necessary, use Viking’s K-1900-7 or combine the K-1500 Series phones with Viking’s K-1900-5 Hot-Line Dialer.

The K-1500 Series phones consist of a heavy gauge stainless steel panel, an armored cable, a heavy duty black amplified handset, and an all metal cradle. Both phones are designed to mount to a standard double gang electrical box.



Applications:
Ringdown phones
Catalog sales
Kiosks in malls
Courtesy and customer service phones
Automated tellers
Security and emergency phones
Hot-Line phone when used with a K-1900-5 Hot-Line Dialer
Point to point communication when used with the DLE-200B Line Simulator.

Features:
Operates on C.O. lines or analog PABX/KSU stations
Flush mounts to a standard double gang box
Optional VE-5x10 Surface Mount Box (K-1500-7 only)
Optional VE-9x20 Weatherproof Box (K-1500-7 only)

Specifications:
Power: Telephone line powered
Dimensions: K-1500-6 - 115mm x 115mm x 100mm (4.5” x 4.5” x 4”), K-1500-7 - 127mm x 254mm x 102mm (5” x 10” x 4”)
Shipping Weight: K-1500-6 - 0.9 kg (2 lbs), K-1500-7 - 1.8 kg (4 lbs)
Environmental: 0°C to 32°C (32°F to 90°F) with 5% to 95% noncondensing humidity
Connections: (1) RJ11 jack
Panel Material: .125 inch stainless steel
Mounting: Flush mountable to a standard double gang box
