The ProSafe™ Gigabit Stackable Smart PoE (Power over Ethernet) Switches are specifically designed for growing small and mid-sized businesses (SMB) with advanced network needs for the support of multiple "new-world" applications: Voice over IP (VoIP), a unified wired/wireless network, IP surveillance, converged video and data network and much more. It delivers the scalability, flexibility, reliability, and performance the SMB customers need in an affordable and easy-to-manage package.



Each ProSafe™ Gigabit Stackable Smart PoE Switch comes with 24 10/100/1000 Mbps ports and four shared SFP ports. All ports support standards-based PoE and as a first in the industry, they also support IEEE 802.3at-based PoE+ on the first 4 ports of each switch, capable of providing up to 30W of power to higher-powered PoE devices such as dual-band N Wireless access points, videophones and IP cameras with pan/tilt/zoom capabilities. Coupled with autovoice VLAN feature, the switch greatly reduces the complexity of VoIP deployment, and makes it easy for SMBs to implement and manage a VoIP system on their network.



The stacking feature on these switches provides the SMB with uncompromised performance, scalability and ease of network management. The only Gigabit Smart Stackable switches in the industry, they can be stacked through dedicated high-speed stacking ports (HDMI-based) with an aggregate 20 Gbps bandwidth, ensuring that the traffic between the stacked switches won't be compromised. Customers can scale up to 6 switches in one stack, and all of them can be easily configured and managed as one switch. Businesses can add switches to the stack as their network expands without making a big upfront investment at the beginning. Meanwhile, the stack's redundancy and hot-swappable capability help boost network resiliency. Under the same Gigabit Stackable Smart Switch family, the GS724TPS and GS748TPS switches can be stacked together with GS724TS and GS748TS.



These switches come with a complete suite of advanced features such as access control lists (ACL), 802.1x port authentication, enhanced QoS, rate limiting and IGMP snooping, among others, to provide SMB businesses with more robust security, higher quality of service and high availability.



An intuitive, Web browser interface provides simple yet comprehensive management, making it extremely simple to deploy and manage the advanced features, in order to realize the potential of a converged network and deliver lower total cost of ownership.



Network Protocol and Standards Compatibility

• IEEE 802.3 10BASE-T
• IEEE 802.3u 100BASE-TX
• IEEE 802.3ab 1000BASE-T
• IEEE 802.3z 1000BASE-X
• IEEE 802.3x full-duplex flow control

Interfaces

• 24 10/100/1000 Mbps switching ports
• 4 Built-in shared SFP Gigabit Ethernet fiber ports for 100/1000 Mbps connectivity
• 2 HDMI ports on the rear of the unit – used for stacking only
• Auto-sensing and auto-negotiating capabilities for all copper ports
• Auto Uplink™ on all ports to make the right connection

Administrative Switch Management

• IEEE 8021.Q VLAN (128 groups, Static)
• IEEE 802.1p Class of Service (CoS)
• 4 hardware queues
• Port-based QoS
• IEEE 802.3ad Static or Dynamic Link Aggregation (LACP)
• IEEE 802.1D Spanning Tree Protocol
• IEEE 802.1w Rapid Spanning Tree Protocol
• IEEE 802.1s Multiple Spanning Tree Protocol
• SNMP v1, v2c, v3
• RFC 1213 MIB II
• RFC 1643 Ethernet Interface MIB
• RFC 1493 Bridge MIB
• RFC 2131 DHCP client
• IEEE 802.1x (RADIUS)
• RADIUS accounting
• Layer 3 (DSCP) Quality of Service (QoS)
• TACACS+
• TCP/UPD-based priority mapping
• IGMP snooping
• Port-based security by locked MAC addresses
• MAC and IP address ACL
• Storm control for broadcast, multicast and unknown unicast packets
• Port-based ingress/egress rate limiting
• SNTP
• RMON group 1, 2, 3, 9
• Private Enterprise MIB
• Port mirroring – many-to-one
• IEEE 802.3ab LLDP
• LLDP-MED
• Protected ports
• Cable test
• Web-based configuration
• Configuration backup/restore
• Password access control
• Firmware upgradeable

Performance Specifications

• Forwarding modes: Store-and-forward
• Bandwidth: 48 Gbps
• Stacking up to 6 switches or 288 ports per stack
• Stacking bandwidth: 20 Gbps
• Network latency: Less than 3 microseconds for 64-byte frames in store-and-forward mode for 1000 Mbps to 1000 Mbps transmission
• Buffer memory: 2 Mb
• Address database size: 8,000 media access control (MAC) addresses per system
• Addressing: 48-bit MAC address
• Mean time between failures (MTBF): 116,000 hours (~13 years) at 25º C

LEDs

• Unit: Power, fan, stack master, stack ID, PoE max, LED mode
• Per port: Link, speed, activity, stack

Power Supply

• Power consumption: 235W for GS724TPS
• 100-240V AC/50-60 Hz universal input
• PoE Budget: 192 Watts

Physical Specifications

• Dimensions: (h x w x d): 43 x 440 x 310 mm (1.7 x 17.32 x 12.2 in)
• Weight: 4.92 kg (10.824 lb)

Environmental Specifications

• Operating temperature: 32° to 122° F (0° to 50° C)
• Storage temperature: -4° to 158° F (-20° to 70° C)
• Operating humidity: 90% maximum relative humidity, non-condensing
• Storage humidity: 95% maximum relative humidity, non-condensing
• Operating altitude: 10,000 ft (3,000 m) maximum
• Storage altitude: 10,000 ft (3,000 m) maximum
• Acoustic noise: 46 dBA

Electromagnetic Compliance

• CE mark, commercial
• FCC Part 15 Class A
• VCCI Class A
• EN 55022 (CISPR 22),
• EN 55024 (CISPR 24)
• C-Tick
• CCC

Safety

• CE mark, commercial
• CUL 60950 (Listed)/EN 60950 (Low Voltage Directive)
• CB
• CCC

Warranty and Support

• ProSafe Lifetime Warranty†
• ProSupport 24x7 Advanced Technical Support, 1 year (included)
