SKU: 1184015G5
Brand: Adtran
Adtran OPTI-6100 Y-Cable Splitter SC:LC
List Price: $287.00
Price: $196.95
You Save: $90.05 (31%)
Add to Wishlist Add to Wishlist
1184015G5
1184015G5
Previous Item Previous Item   Next Item Next Item
Product Details
  • Connects two optical devices to a single fiber span, or routes a single optical signal onto two different fibers
  • Can only transmit one signal at a time (does not provide a multiplexing function), so use with two optical devices is best accomplished in a redundant configuration where only one device is online at any one time
  • Bi-directional, and can be used in either the Transmit (Tx) or Receive (Rx) direction, at either end of a fiber span, depending on the function it is to provide
Features and Benefits
  • Fiber leads are 3 meters each in length
  • SC connector on composite fiber lead
  • LC/UPC connectors on split fiber leads
  • Insertion Loss < 3.8dB
  • Wavelength: 1310 nm ± 40 nm, 1550 nm ± 40 nm
  • Operational Temperature Range: -10°C to +70°C
  • Storage Temperature Range: -40°C to +85°C
