Teledex DIAMOND DIAMOND+S-5 BUTTON Ash (00G1070-005)
- Single-Line Guestroom Speakerphone
- Five (5) Guest Service Buttons
- HAC/VC (ADA) Handset Volume Boost with 3 distinct levels
- Easy Access Data Port
- ExpressNet-ready
- Raised Red Message Waiting lamp
- Patented MultiX Message Waiting Circuitry
- Speaker On/Off Key with red LED
- Hold with Hold Release detection circuit
- Mute with LED indicator
- Redial
- Textured Finish
- Supports Full-length Paper Faceplate
- Desk or Wall Mountable
- Hidden Programming Key
|
| Specifications |
| Handset | Standard K Style (Euro Style optional), Hearing aid compatible |
| Handset Cord Length | 10 feet/ 3.05 meters |
| Line Cord Length | 10 feet/ 3.05 meters |
| Cabling Requirement | 2 Pair Minimum |
| Signaling | Standard 12 tone DTMF |
| Flash Timing | 600 ms |
| Message Waiting | 90-120 VDC |
| Operating Voltage | 24 to 56 VDC Non Polarity |
| FCC Specifications | Meets Part 15, Subpart J, Class A, Part 68 |
| International PTT Registrations | Available upon request. |
| Safety Standard | ETL and CE |
| Ringer Equivalence | Z |
| Registered Connector | USOC RJ 14 |
| Footprint | 6.25 in x 9.0 in., 15.9 cm x 22.9 cm |
| Weight | @ 2.3 lbs./ 1 kilo |
