A Modular Access Router pre-configured with the T1/FT1+ DSX-1 NIM. The NetVanta 3205 includes one Ethernet LAN port, a built-in firewall for network security, QoS to priority delay sensitive traffic like VoIP, DHCP to assign IP addresses, and Network Address Translation (NAT) as well to conceal private address.
- Supports up to dual-T1s worth of bandwidth
- Interchangeable Network Interface Modules (NIMs)
- Stateful inspection firewall protects against Denial of Service (DoS) attacks
- QoS with Low Latency and Weighted Fair Queuing and DiffServ marking for delay sensitive traffic like VoIP
- PPP dial backup for disaster recovery scheme back to a PPP compliant device
- VLAN trunking allows routing between VLANs
- Built-in DSU/CSU protects circuit - Requires Option Module
- Supports BGP, OSPF, RIP, static routes, and bridging
- Network Address Translation (NAT/NAPT) conceals private IP addresses
- NAT-compatible SIP ALG
- Auto-sensing 10/100BaseT interface to accommodate mixed Ethernet environments
- Command Line Interface (CLI) which mimics de facto industry standard and a user-friendly web-GUI
- Optional DSX-1 interface available for voice connectivity to a PBX
- Optional Analog or ISDN BRI dial backup system prevents network downtime
- Optional VPN - 5 IPSec tunnels using DES/3DES/AES encryption
- Optional Analog Modem module used for dial backup or remote management
-
Industry-leading five-year warranty
-
A single RJ-48C connector for T1 connectivity
-
A single RJ-48C connector for DSX-1
