VE-9X20R-0
VE-9X20R-0 by Viking Electronics (Factory New) Red Heavy-Duty Outdoor Enclosure with Optional Telephone Label (UPC 615687224320 ) is listed under various telecommunications in the Viking Electronics telecommunications / telephony section.
The VE-9x12 and VE-9x20 outdoor enclosures provide the ultimate in weather
protection for your Viking product or other device. The VE-9x12 enclosures are
constructed of glass fiber reinforced durable UV stable plastic. The VE-9x20
enclosures are constructed of cast aluminum. Both
models are made for years of outdoor service. The
heavy-duty doors are labeled “Telephone” and have a
gasket seal to keep out even the harshest weather. The
VE-9x12 allows you to choose from two panels that allow
mounting many different Viking products.
Both the VE-9x12 and VE-9x20 are available in three
high visibility colors: red with silver lettering, yellow with
red lettering, or black with silver lettering.
Models VE-9x12-0P and VE-9x20-0 come without an
adapter panel, ideal for mounting non-Viking equipment.
These enclosures come in all three colors and include a
separate “Telephone” label.
Features:
- Heavy cast aluminum construction
- Gasket sealed door
- Drip guard
- 3/4" NPT conduit openings
- Push-button Latch
- Emergency Red
- Hardware included
- Universal mounting adapters for multiple products
- Compatible with these Viking products: K-1500-7, K-1900-7 and K-1900-11
- Optional VE-PBL push button lock and key set available
Technical Specifications:
- Dimensions: Overall - 235mm x 324mm x 203mm (9.25" x 20.25" x 8"), Approximate Maximum Internal Clearance - 129mm x 285mm x 114mm (5.75" x 17.25" x 6.75")
- Shipping Weight: 7.3 kg (16 lbs.)
- Colors: Red with white lettering
- Conduit opening: " NPT with plug, top and bottom
