99510-45-01

SKU: 99510-45-01
Coleman Cable RG59 20BC 95% Braid CM, White, 500'
List Price: $131.26
Price: $59.59
You Save: $71.67 (55%)
99510-45-01
99510-45-01
Product Details
DESCRIPTION:
RG-59/U Coaxial cable with 95% braid

RATING:
ETL Listed as CM/CL2

CONSTRUCTION PARAMETERS:
Conductors: 20 AWG (1/.032) Solid Bare Copper 0.032
Dielectric: Foam Polyethylene color natural 0.057 0.146
Shielding: 95% Braid 0.168
Jacket: PVC

ELECTRICAL PROPERTIES:
Impedance (ohms): 75
Capacitance (pF/ft): 17
Velocity of Propagation (%): 78

MISCELLANEOUS INFORMATION:
Jacket Color: Black or White(ordered separately)
Flame Rating: UL-1581 Vertical Tray Flame Test
Max. Operating Temperature: 75o C
Applicable NEC Article: 725
Approx. Weight (lb/1000 ft): 24
