DESCRIPTION:
RG-59/U Coaxial cable with 100% bonded foil shield and 95% tinned copper braid

RATING:
ETL Listed as CL2

CONSTRUCTION PARAMETERS:
Conductors: 20 AWG (1/.032) Solid Bare Copper
Dielectric: Foam Polyethylene color natural
Shielding: Aluminum/Polyester/Aluminum Fusible Tape plus 95% Tinned Copper Braid
Jacket: PVC
Color: Blue

ELECTRICAL PROPERTIES:
Impedance (ohms): 75
Capacitance (pF/ft): 17.5
Velocity of Propagation (%): 78

MISCELLANEOUS INFORMATION:
Flame Rating: UL-1581 Vertical Tray Flame Test
Max. Operating Temperature: 60o C
Applicable NEC Article: 725
Approx. Weight (lb/1000 ft): 37
Packaging: 500ft Pull-box
