993253-06-08

SKU: 993253-06-08
Coleman Cable RG59 20BC 95%BC & 18/2 STR BC Siamese CM (1000 FT) BLACK, UPC: 029892706173
List Price: $414.00
Price: $225.00
You Save: $189.00 (46%)
993253-06-08
993253-06-08
Product Details
DESCRIPTION:
COMBO RG59 COAXIAL PLUS 2 COND/18 AWG IN SIAMESE LAYUP

RATING:
C(ETL)US LISTED AS CM/CL2 CMH FT1

CONSTRUCTION PARAMETERS:
Part 1:
Conductor: 20 AWG (1/.032) Solid Bare Copper
Dielectric: Foam Polyethylene color natural
Shielding: 95% Copper Braid
Part 2:
Conductor: 18 AWG (7/.015) Stranded Bare Copper
Dielectric: Foam Polypropylene
Color Code: Black & Red
Final:
Jacket: PVC extruded over Part 1 and Part 2 with web attached

ELECTRICAL PROPERTIES:
Impedance (ohms): 75
Capacitance (pF/ft): 17
Velocity of Propagation (%): 78

MISCELLANEOUS INFORMATION:
Jacket Color: Black or White(ordered separately)
Applicable NEC Article: 725 & 800
Voltage: 300V
Flame rating: UL-1581 Vertical Tray Flame Test
Approximate Weight (lb/1000 ft): 51
