Message Waiting Lamp



Provides Visual Lamp Indication of Message Waiting and Ringing

The message waiting lamp retrofit kit is compatible with any telephone system with standard DC message waiting voltages ranging from 90VDC to 120 VDC.

The LM-1A is fully modular for quick plug-in installation by non-telephone personnel. The units LED will blink at a steady rate when the message waiting voltage is detected.

The LM-1A will also flicker when the phone rings, helping to reduce noise in quiet areas by providing a convenient visual indication for ringing or message waiting.

Note: The LM-1A is not compatible with any AT&T phone system.

Applications
Message waiting indication on analog lines supplying standard message waiting voltages
Ring indicator in offices

Features
Attractive styling
Easy retrofit mounting
Works with nearly all message waiting voltages
One year warranty
Made in the USA

Specifications
Input: 80V DC to 150V DC message waiting voltage, minimum 40V AC ring voltage
Viewing Distance: Up to 15m (50 feet)
Dimensions: 65mm x 35mm x 20mm (2.56in x 1.38in x .79in)
Environmental: 0 C to 32 C (32 F to 90 F) with 5% to 95% non-condensing humidity
Connections: (2) RJ11 plugs
