This auxiliary electronic ringer operates on any analog line that provides a minimum of 40 volts 20-30 Hz AC ring voltage. Nominal 3 KHz warble provides up to 92 dB SPL @ 1 meter. The LPR-1 can be connected via screw terminals or modular RJ-11 jack. A volume control and a 7 foot modular cord are provided. No power supply is required.



Applications Single line loud ringing Night bell ringing Business/offices/small warehouses Floating employee

Features Loud ringing from an analog line Connect via screw terminals or modular RJ-11 jack 7 ft line cord provided Adjustable volume control

Specifications Dimensions: 76mm x 112mm x 36mm (3.0” x 4.4” x 1.4”) Shipping Weight: 0.5 kg (1.1 lbs) Environmental: 0°C to 32°C (32°F to 90°F) with 5% to 95% noncondensing humidity Maximum Sound Pressure: 92 dB SPL @ 1 meter (nominal) Minimum Ring Voltage: 40V AC RMS @ 20-30 Hz Connections: (2) cage clamp screw terminals (1) modular RJ-11 jack
