The ZyWALL SSL2TO5USG100 is a Unified Security Gateway, integrated with complete, enterprise-level and advanced security solutions designed for Small/Medium Business (SMB) recommended for up to 25 PC users. Its flexible configuration helps network administrators set up the network and enforce security policies more efficiently.

It also provides bandwidth management, for QoS of VoIP or mission critical applications, Multiple-WAN Failover and Load Balancing. Moreover, IPSec VPN and SSL VPN design for telecommuters and home workers can access data more easily and safely at home. Remote access with SSL VPN requires only a standard web browser. ZyWALL USG 100's excellent throughput is the key to implement features of an enterprise level to provide a full-time, non-stop and secure service.





	The ICSA-certified, stateful inspection firewall protects the network and vital Internet services like e-mail, Web browsing, servers and file transfers
	For protection against viruses and spyware, choose the ICSA-certified ZyXEL Anti-Virus or one powered by Kaspersky Labs
	The IDP engine protects your network from intrusions such as Trojans and worms
	Use IPSec VPN to secure connections to branch offices, partners and headquarters. Road warriors and telecommuters can use SSL or L2TP VPN to securely access the company network without having to install VPN software
	Application Patrol controls who can use what IM and P2P applications like MSN and BitTorrent and even who can use specific features within an application
	The anti-spam feature can tag or discard unsolicited commercial or junk e-mail
	User-aware configuration lets you control access to applications or resources and apply security scans by user or user group
	Bandwidth management lets you prioritize time-sensitive applications like VoIP and video conferencing
	Multiple WAN ports let you use multiple ISP links and load balancing to enhance traffic. Throughput, optimize bandwidth usage and help ensure continuous uptime if a link goes down
	Along with your regular user name and password, use the ZyWALL OTP (One Time Password). hardware token* to generate a new PIN code each time you log in
	Use the extension card slot and USB ports for multiple 3G wireless WAN connections



Specifications:

SSL VPN	Clientless Secure Remote Access(Reverse Proxy Mode) SecuExtender (Full Tunnel Mode) A Unified Policy Enforcement Supports Two-factor Authentication Customizable User Portal
User Licenses	Unlimited
Networking	Routing Mode/Bridge Mode/Mixed Mode Layer 2 Port Grouping Ethernet/PPPoE/PPTP Tagged VLAN (802.1Q) Virtual Interface (Alias Interface) Policy-Based Routing (User-Aware) Policy-Based NAT (SNAT/DNAT) RIP v1/v2 OSPF IP Multicasting (IGMP v1/v2) DHCP Client/Server/Relay Built-in DNS Server Dynamic DNS
Authentication	Internal User Database Microsoft Windows Active Directory External LDAP/RADIUS User Database ZyWALL OTP (One Time Password) Forced User Authentication (Transparent Authentication)
System Management 1	Role-Based Administration Multiple Administrator Login Multi-Lingual Web GUI (HTTPS/HTTP) Object-Based Configuration Command Line Interface (Console/Web Console/SSH/TELNET) Comprehensive Local Logging Syslog (send to up to 4 servers) E-mail Alert (send to up to 2 servers) SNMP v2c (MIB-II)
System Management 2	Real-Time Traffic Monitoring System Configuration Rollback Text-Based Configuration File Firmware upgrade via FTP/FTP-TLS/Web GUI Advanced Reporting (Vantage Report) Centralized Network Management (Vantage CNM)
3G Support	Advanced Wireless Security Transmission with WEP Encryption and WPA/WPA2 Support PCMCIA: Sierra Wireless AC850 USB: Huawei E220
Certifications	ICSA Certified Firewall ICSA Certified IPSec VPN ICSA Certified Anti-Virus
Standards Compliance	HSF (Hazardous Substance Free): RoHS and WEEE EMC: FCC Part 15 Class B, CE-EMC Class B, C-Tick Class B, VCCI Class B Safety: CSA International (ANS/UL60950-1,CSA60950-1, EN60950-1, IEC60950-1)
Memory size	256 MB DDR2 RAM/256 MB Flash
Interface	GbE x 7 (RJ-45 with) Auto-negotiation and Auto MDI/MDI-X
Console	RS-232 (DB9F)
AUX	RS-232 (DB9M)
LED Indicator	PWR, SYS, AUX, CARD
Reset Button	Yes
Expansion Card Slot	Yes
USB Ports	2
Power Requirements	Input: 100 - 240 V; 1.2 A, 50 - 60 Hz Output: 12 V; 3.5 A
Operating temperature	0deg.C - 50deg.C/32deg.F - 122deg.F
Storage temperature	-30deg.C - 60deg.C/-22deg.F - 140deg.F
Operating humidity	5% - 90% (noncondensing)
Dimensions (W x D x H)	242 x 175 x 35.5 mm/9.5 x 6.9 x 1.4 in
Weight	1.2 Kg/2.6 lbs
