Enhanced Network Audio Port
The VIP-801A Networked Page Zone Extender enables voice access to a single zone of one-way paging over an IP-based LAN/WAN. This allows page zone extension anywhere on the network.
Features:
- 1 Audio output
- 2 Programmable form C relay closures
- No server required
- 1 to 11 Digit dial plans
- Easy windows based setup
- AUX Audio input
- Audio Indication
- Door Unlocking
Specifications:
- VoIP Remote handset paging system access to networked VIP-800 audio adapters
- Point to point or multi-point communication to other telephones and PagePac station doorphone call in stations
- Ringdown circuit
- Information phones - using ringdown with 2500 set
Input:
- Analog device line interface-
- 600 Ohm Input Impedance
- VOX and Contact closure input
Output
- Analog output interface
- Less than 50 Ohms output impedance
- Frequency Response: 200 Hz – 3400 Hz
- Relay closure available
